Vishay/Dale M55342E12B226DRWS
- Mfg. Part Number
- M55342E12B226DRWS
- Manufacturer
- Vishay/Dale
- Product Category
- Chip Resistor - Surface Mount
- Brief Description
- RES SMD 226 OHM 1% 1/10W 0603
- Datasheet Download
- M55342E12B226DRWS.pdf
Availability of M55342E12B226DRWS
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 5.54400
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of M55342E12B226DRWS, we specialize in Vishay/Dale all series electronic components. M55342E12B226DRWS can be shipped within 24 hours after order. If you have any demands for M55342E12B226DRWS, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- M55342E12B226DRWS Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
M55342E12B226DRWS
| Internal Part Number | EIS-M55342E12B226DRWS | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| PCN Assembly/Origin | TF-001-2014-Rev-0 20/Jan/2014 | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 1 | |
| Category | Resistors | |
| Family | Chip Resistor - Surface Mount | |
| Series | Military, MIL-PRF-55342, RM0603 | |
| Packaging | Tray - Waffle | |
| Resistance (Ohms) | 226 | |
| Tolerance | ±1% | |
| Power (Watts) | 0.1W, 1/10W | |
| Composition | Thin Film | |
| Features | Military, Non-Inductive | |
| Temperature Coefficient | ±25ppm/°C | |
| Package / Case | 0603 (1608 Metric) | |
| Supplier Device Package | 0603 | |
| Size / Dimension | 0.064" L x 0.032" W (1.63mm x 0.81mm) | |
| Height | 0.033" (0.84mm) | |
| Number of Terminations | 2 | |
| Failure Rate | R (0.01%) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | M55342E12B226DRWS | |
| Related Links | M55342E1, M55342E12B226DRWS Datasheet, Vishay/Dale Distributor | |
M55342E12B226DRWS Details Description
