Maxim Integrated MAX7221CWG+
- Mfg. Part Number
- MAX7221CWG+
- Manufacturer
- Maxim Integrated
- Product Category
- PMIC - Display Drivers
- Brief Description
- IC DRIVER LED DISP 8DGT 24-SOIC
- Datasheet Download
- MAX7221CWG+.pdf
Availability of MAX7221CWG+
Available Quantity
7428 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 5.87776
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of MAX7221CWG+, we specialize in Maxim Integrated all series electronic components. MAX7221CWG+ can be shipped within 24 hours after order. If you have any demands for MAX7221CWG+, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- MAX7221CWG+ Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
MAX7221CWG+
| Internal Part Number | EIS-MAX7221CWG+ | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Mfg Application Notes | Data Multiplexer Adds Cursor To MAX7219 or MAX7221 LED 7 Segment Display Driver Migrating from the MAX7219 and MAX7221 to the MAX6950 and MAX6951 LED Drivers 12-Bit Thermometer Using an 8-Bit µC and Assembler Multiplexing Shutdown Allows Text to be Displayed Electronic Displays Comparison Using the MAX7219/7221 to Drive Higher Voltage or Current Using Maxim SPI-compatible Display Drivers with other SPI Peripherals LEDs Are Still Popular (and Improving) after All These Years Using a PC to Experiment with the MAX7219 and MAX7221 LED Display Drivers One-Wire Network Controls Remote SPI Peripherals Eliminate Noise Through Proper Supply Bypass Filtering | |
| Product Training Modules | Lead (SnPb) Finish for COTS Long-Term Supply Program Simple LED Drivers - MAX7219 and MAX7221 | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 30 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Display Drivers | |
| Series | - | |
| Packaging | Tube | |
| Display Type | LED | |
| Configuration | 7 Segment + DP | |
| Interface | 4-Wire Serial | |
| Digits or Characters | 8 Digits | |
| Current - Supply | 330mA | |
| Voltage - Supply | 4 V ~ 5.5 V | |
| Operating Temperature | 0°C ~ 70°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 24-SOIC (0.295", 7.50mm Width) | |
| Supplier Device Package | 24-SOIC W | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | MAX7221CWG+ | |
| Related Links | MAX72, MAX7221CWG+ Datasheet, Maxim Integrated Distributor | |
