NKK Switches MB2085SB1W01/U-DA
- Mfg. Part Number
- MB2085SB1W01/U-DA
- Manufacturer
- NKK Switches
- Product Category
- Pushbutton Switches
- Brief Description
- SWITCH PUSHBUTTON DPDT 6A 125V
- Datasheet Download
- MB2085SB1W01/U-DA.pdf
Availability of MB2085SB1W01/U-DA
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 9.18000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of MB2085SB1W01/U-DA, we specialize in NKK Switches all series electronic components. MB2085SB1W01/U-DA can be shipped within 24 hours after order. If you have any demands for MB2085SB1W01/U-DA, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- MB2085SB1W01/U-DA Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
MB2085SB1W01/U-DA
| Internal Part Number | EIS-MB2085SB1W01/U-DA | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Featured Product | Pushbutton Switches | |
| PCN Design/Specification | M Series Toggles, rockers, Pushbuttons CSA Mark Size 23/Jul/2015 | |
| Standard Package | 1 | |
| Category | Switches | |
| Family | Pushbutton Switches | |
| Series | MB2000 | |
| Packaging | Bulk | |
| Type | Standard | |
| Circuit | DPDT | |
| Switch Function | On-On | |
| Current Rating | 6A (AC), 3A (DC) | |
| Voltage Rating - AC | 125V | |
| Voltage Rating - DC | 30V | |
| Actuator Type | Round, Button | |
| Color - Actuator/Cap | Black | |
| Illumination Type, Color | - | |
| Illumination Voltage (Nominal) | - | |
| Mounting Type | Panel Mount, Rear | |
| Termination Style | Solder Lug | |
| Ingress Protection | - | |
| Features | Epoxy Sealed Terminals | |
| Panel Cutout Dimensions | Circular - 12.50mm Dia | |
| Operating Temperature | -30°C ~ 85°C | |
| Mechanical Life | 100,000 Cycles | |
| Electrical Life | 25,000 Cycles | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | MB2085SB1W01/U-DA | |
| Related Links | MB2085SB, MB2085SB1W01/U-DA Datasheet, NKK Switches Distributor | |
