ON Semiconductor MC74HCT259ADR2G
- Mfg. Part Number
- MC74HCT259ADR2G
- Manufacturer
- ON Semiconductor
- Product Category
- Logic - Latches
- Brief Description
- 8-BIT ADDRESSABLE LATCH
- Datasheet Download
- MC74HCT259ADR2G.pdf
Availability of MC74HCT259ADR2G
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.09812
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of MC74HCT259ADR2G, we specialize in ON Semiconductor all series electronic components. MC74HCT259ADR2G can be shipped within 24 hours after order. If you have any demands for MC74HCT259ADR2G, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- MC74HCT259ADR2G Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
MC74HCT259ADR2G
| Internal Part Number | EIS-MC74HCT259ADR2G | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 2,500 | |
| Category | Integrated Circuits (ICs) | |
| Family | Logic - Latches | |
| Series | 74HCT | |
| Packaging | Tape & Reel (TR) | |
| Logic Type | D-Type, Addressable | |
| Circuit | 1:8 | |
| Output Type | Standard | |
| Voltage - Supply | 4.5 V ~ 5.5 V | |
| Independent Circuits | 1 | |
| Delay Time - Propagation | 42ns | |
| Current - Output High, Low | 5.2mA, 5.2mA | |
| Operating Temperature | -55°C ~ 125°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 16-SOIC (0.154", 3.90mm Width) | |
| Supplier Device Package | 16-SOIC | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | MC74HCT259ADR2G | |
| Related Links | MC74HCT, MC74HCT259ADR2G Datasheet, ON Semiconductor Distributor | |
MC74HCT259ADR2G Details Description
