NXP Semiconductors/Freescale Semiconductor, Inc. MC9S08PA8VTG
- Mfg. Part Number
- MC9S08PA8VTG
- Manufacturer
- NXP Semiconductors/Freescale Semiconductor, Inc.
- Product Category
- Embedded - Microcontrollers
- Brief Description
- IC MCU 8BIT 8KB FLASH 16TSSOP
- Datasheet Download
- MC9S08PA8VTG.pdf
Availability of MC9S08PA8VTG
Available Quantity
5143 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.69600
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of MC9S08PA8VTG, we specialize in NXP Semiconductors/Freescale Semiconductor, Inc. all series electronic components. MC9S08PA8VTG can be shipped within 24 hours after order. If you have any demands for MC9S08PA8VTG, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- MC9S08PA8VTG Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
MC9S08PA8VTG
| Internal Part Number | EIS-MC9S08PA8VTG | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Design Resources | Development Tool Selector | |
| PCN Design/Specification | 9S08PTxx, 9S08PAxx Errata Update 11/Jul/2013 Errata Update 12/Nov/2013 Manual/Datasheet/Errata Update 26/Sep/2014 | |
| PCN Assembly/Origin | Fabrication Site Transfer 05/Nov/2014 Assembly Site Expansion 13/Feb/2015 | |
| Standard Package | 96 | |
| Category | Integrated Circuits (ICs) | |
| Family | Embedded - Microcontrollers | |
| Series | S08 | |
| Packaging | Tray | |
| Core Processor | S08 | |
| Core Size | 8-Bit | |
| Speed | 20MHz | |
| Connectivity | I²C, LIN, SPI, UART/USART | |
| Peripherals | LVD, POR, PWM, WDT | |
| Number of I/O | 14 | |
| Program Memory Size | 8KB (8K x 8) | |
| Program Memory Type | FLASH | |
| EEPROM Size | 256 x 8 | |
| RAM Size | 2K x 8 | |
| Voltage - Supply (Vcc/Vdd) | 2.7 V ~ 5.5 V | |
| Data Converters | A/D 12x12b | |
| Oscillator Type | Internal | |
| Operating Temperature | -40°C ~ 105°C | |
| Package / Case | 16-TSSOP (0.173", 4.40mm Width) | |
| Supplier Device Package | 16-TSSOP | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | MC9S08PA8VTG | |
| Related Links | MC9S08, MC9S08PA8VTG Datasheet, NXP Semiconductors/Freescale Semiconductor, Inc. Distributor | |
