Crydom MCSS4850AM
- Mfg. Part Number
- MCSS4850AM
- Manufacturer
- Crydom
- Product Category
- Solid State Relays
- Brief Description
- RELAY START/STOP 480V 50A AC OUT
- Datasheet Download
- MCSS4850AM.pdf
Availability of MCSS4850AM
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 103.33000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of MCSS4850AM, we specialize in Crydom all series electronic components. MCSS4850AM can be shipped within 24 hours after order. If you have any demands for MCSS4850AM, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- MCSS4850AM Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
MCSS4850AM
| Internal Part Number | EIS-MCSS4850AM | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Other Related Documents | Declaration of Conformity | |
| 3D Model | MCS Series.stpMCS Series.satMCS Series.dwg | |
| Standard Package | 10 | |
| Category | Relays | |
| Family | Solid State Relays | |
| Series | MCS | |
| Packaging | Bulk | |
| Circuit | SPST-NO (1 Form A) | |
| Output Type | AC, Linear Controlled | |
| On-State Resistance | - | |
| Load Current | 50A | |
| Voltage - Input | 8 ~ 32VDC | |
| Voltage - Load | 300 ~ 530 V | |
| Mounting Type | Chassis Mount or Panel Mount | |
| Termination Style | Screw Terminal | |
| Package / Case | Hockey Puck | |
| Supplier Device Package | - | |
| Relay Type | Relay | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | MCSS4850AM | |
| Related Links | MCSS4, MCSS4850AM Datasheet, Crydom Distributor | |
MCSS4850AM Details Description
