ITT Cannon, LLC MKJ3C7W6-7DN
- Mfg. Part Number
- MKJ3C7W6-7DN
- Manufacturer
- ITT Cannon, LLC
- Product Category
- Circular Connectors
- Brief Description
- CONN RCPT 7POS JAM NUT W/SKTS
- Datasheet Download
- MKJ3C7W6-7DN.pdf
Availability of MKJ3C7W6-7DN
Available Quantity
5035 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 53.35200
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of MKJ3C7W6-7DN, we specialize in ITT Cannon, LLC all series electronic components. MKJ3C7W6-7DN can be shipped within 24 hours after order. If you have any demands for MKJ3C7W6-7DN, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- MKJ3C7W6-7DN Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
MKJ3C7W6-7DN
| Internal Part Number | EIS-MKJ3C7W6-7DN | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Featured Product | MKJ (Trinity) Series | |
| Standard Package | 1 | |
| Category | Connectors, Interconnects | |
| Family | Circular Connectors | |
| Series | MIL-DTL-38999, MKJ3 | |
| Packaging | Bulk | |
| Connector Type | Receptacle, Female Sockets | |
| Number of Positions | 7 | |
| Shell Size - Insert | 6-7 | |
| Shell Size, MIL | - | |
| Mounting Type | Panel Mount, Bulkhead; Through Hole | |
| Termination | Solder | |
| Fastening Type | Bayonet Lock | |
| Orientation | N (Normal) | |
| Ingress Protection | - | |
| Shell Material, Finish | Aluminum Alloy, Olive Drab Cadmium Plated | |
| Contact Finish | Gold | |
| Features | Shielded | |
| Contact Finish Thickness | 50µin (1.27µm) | |
| Current Rating | 5A | |
| Voltage - Rated | 500VAC | |
| Operating Temperature | -55°C ~ 150°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | MKJ3C7W6-7DN | |
| Related Links | MKJ3C7, MKJ3C7W6-7DN Datasheet, ITT Cannon, LLC Distributor | |
