Caddock Electronics Inc. MP9100-0.50-1%
- Mfg. Part Number
- MP9100-0.50-1%
- Manufacturer
- Caddock Electronics Inc.
- Product Category
- Through Hole Resistors
- Brief Description
- RES 0.5 OHM 100W 1% TO247
- Datasheet Download
- MP9100-0.50-1%.pdf
Availability of MP9100-0.50-1%
Available Quantity
5110 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 8.15400
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of MP9100-0.50-1%, we specialize in Caddock Electronics Inc. all series electronic components. MP9100-0.50-1% can be shipped within 24 hours after order. If you have any demands for MP9100-0.50-1%, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- MP9100-0.50-1% Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
MP9100-0.50-1%
| Internal Part Number | EIS-MP9100-0.50-1% | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Other Related Documents | Product Overview | |
| Mfg Application Notes | Understanding MP9100 Resistors Power Rating | |
| Standard Package | 25 | |
| Category | Resistors | |
| Family | Through Hole Resistors | |
| Series | Kool-Pak®MP9000 | |
| Packaging | Tube | |
| Resistance (Ohms) | 0.5 | |
| Tolerance | ±1% | |
| Power (Watts) | 100W | |
| Composition | Thick Film | |
| Features | Moisture Resistant, Non-Inductive | |
| Temperature Coefficient | -20/ +80ppm/°C | |
| Operating Temperature | -55°C ~ 175°C | |
| Package / Case | TO-247-2 | |
| Supplier Device Package | TO-247 | |
| Size / Dimension | 0.620" L x 0.195" W (15.75mm x 4.95mm) | |
| Height | 0.825" (20.96mm) | |
| Number of Terminations | 2 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | MP9100-0.50-1% | |
| Related Links | MP9100-, MP9100-0.50-1% Datasheet, Caddock Electronics Inc. Distributor | |
MP9100-0.50-1% Details Description
