Monolithic Power Systems Inc. MPQ8039GN
- Mfg. Part Number
- MPQ8039GN
- Manufacturer
- Monolithic Power Systems Inc.
- Product Category
- PMIC - Full, Half-Bridge Drivers
- Brief Description
- IC HALF-BRIDGE PWM 8-SOIC
- Datasheet Download
- MPQ8039GN.pdf
Availability of MPQ8039GN
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 2.11500
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of MPQ8039GN, we specialize in Monolithic Power Systems Inc. all series electronic components. MPQ8039GN can be shipped within 24 hours after order. If you have any demands for MPQ8039GN, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- MPQ8039GN Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
MPQ8039GN
| Internal Part Number | EIS-MPQ8039GN | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 2A (4 Weeks) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| RoHS Information | RoHS/Lead Free Policy | |
| Standard Package | 100 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Full, Half-Bridge Drivers | |
| Series | Automotive, AEC-Q100 | |
| Packaging | Tube | |
| Output Configuration | Half Bridge | |
| Applications | General Purpose | |
| Interface | PWM | |
| Load Type | Inductive | |
| Technology | Power MOSFET | |
| Rds On (Typ) | 100 mOhm | |
| Current - Output / Channel | 4.25A | |
| Current - Peak Output | 9A | |
| Voltage - Supply | 7.5 V ~ 24 V | |
| Voltage - Load | 7.5 V ~ 24 V | |
| Operating Temperature | -40°C ~ 125°C (TJ) | |
| Features | - | |
| Fault Protection | Current Limiting, Over Temperature, UVLO | |
| Mounting Type | Surface Mount | |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) Exposed Pad | |
| Supplier Device Package | 8-SOIC-EP | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | MPQ8039GN | |
| Related Links | MPQ8, MPQ8039GN Datasheet, Monolithic Power Systems Inc. Distributor | |
