Amphenol Aerospace Operations MS27484T20F39PA
- Mfg. Part Number
- MS27484T20F39PA
- Manufacturer
- Amphenol Aerospace Operations
- Product Category
- Circular Connectors
- Brief Description
- CONN PLUG 39POS STRAIGHT W/PINS
- Datasheet Download
- MS27484T20F39PA.pdf
Availability of MS27484T20F39PA
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 76.28520
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of MS27484T20F39PA, we specialize in Amphenol Aerospace Operations all series electronic components. MS27484T20F39PA can be shipped within 24 hours after order. If you have any demands for MS27484T20F39PA, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- MS27484T20F39PA Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
MS27484T20F39PA
| Internal Part Number | EIS-MS27484T20F39PA | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Featured Product | MIL-DTL-38999 Series I, II | |
| Standard Package | 1 | |
| Category | Connectors, Interconnects | |
| Family | Circular Connectors | |
| Series | Military, MIL-DTL-38999 Series II | |
| Packaging | Bulk | |
| Connector Type | Plug, Male Pins | |
| Number of Positions | 39 | |
| Shell Size - Insert | 20-39 | |
| Shell Size, MIL | - | |
| Mounting Type | Free Hanging (In-Line) | |
| Termination | Crimp | |
| Fastening Type | Bayonet Lock | |
| Orientation | A | |
| Ingress Protection | Environment Resistant | |
| Shell Material, Finish | Aluminum, Nickel Plated, Electroless | |
| Contact Finish | Gold | |
| Features | Shielded | |
| Contact Finish Thickness | 50µin (1.27µm) | |
| Current Rating | 7.5A, 13A | |
| Voltage - Rated | 600VAC, 850VDC | |
| Operating Temperature | -65°C ~ 200°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | MS27484T20F39PA | |
| Related Links | MS27484, MS27484T20F39PA Datasheet, Amphenol Aerospace Operations Distributor | |
MS27484T20F39PA Details Description
