Texas Instruments MSP430F2254IRHAT
- Mfg. Part Number
- MSP430F2254IRHAT
- Manufacturer
- Texas Instruments
- Product Category
- Embedded - Microcontrollers
- Brief Description
- IC MCU 16BIT 16KB FLASH 40VQFN
- Datasheet Download
- MSP430F2254IRHAT.pdf
Availability of MSP430F2254IRHAT
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 2.47500
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of MSP430F2254IRHAT, we specialize in Texas Instruments all series electronic components. MSP430F2254IRHAT can be shipped within 24 hours after order. If you have any demands for MSP430F2254IRHAT, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- MSP430F2254IRHAT Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
MSP430F2254IRHAT
| Internal Part Number | EIS-MSP430F2254IRHAT | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | The Ultra-Low Power MSP430 MSP430 Overview MSP430 Design Tools MSP430 Peripherals MSP430x2xx/4xx and Wireless Overview Portable Medical Solutions with MSP430 MSP430 for Utility Metering Solutions MSP430: How to JTAG MSP430, How To Use the Clock System Grace Software Graphical User Interface MCU Overview Driver Library MSP430Ware Overview SYS/BIOS: MSP430 Support Microcontrollers: SYS/BIOS: Introduction to SYS/BIOS Threading Intro to Timers and Clocks Microcontrollers: SYS/BIOS: Introduction to Real-Time Operating Systems and SYS/BIOS Communication Solutions for Industrial Automation | |
| Design Resources | Development Tool Selector | |
| Manufacturer Product Page | MSP430F2254IRHAT Specifications | |
| Standard Package | 250 | |
| Category | Integrated Circuits (ICs) | |
| Family | Embedded - Microcontrollers | |
| Series | MSP430F2xx | |
| Packaging | Tape & Reel (TR) | |
| Core Processor | MSP430 | |
| Core Size | 16-Bit | |
| Speed | 16MHz | |
| Connectivity | I²C, IrDA, LIN, SCI, SPI, UART/USART | |
| Peripherals | Brown-out Detect/Reset, POR, PWM, WDT | |
| Number of I/O | 32 | |
| Program Memory Size | 16KB (16K x 8 + 256B) | |
| Program Memory Type | FLASH | |
| EEPROM Size | - | |
| RAM Size | 512 x 8 | |
| Voltage - Supply (Vcc/Vdd) | 1.8 V ~ 3.6 V | |
| Data Converters | A/D 12x10b | |
| Oscillator Type | Internal | |
| Operating Temperature | -40°C ~ 85°C | |
| Package / Case | 40-VFQFN Exposed Pad | |
| Supplier Device Package | 40-VQFN (6x6) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | MSP430F2254IRHAT | |
| Related Links | MSP430F2, MSP430F2254IRHAT Datasheet, Texas Instruments Distributor | |
