ON Semiconductor NIF62514T3G
- Mfg. Part Number
- NIF62514T3G
- Manufacturer
- ON Semiconductor
- Product Category
- PMIC - Power Distribution Switches, Load Drivers
- Brief Description
- IC FET VOLT CLAMP 6A 40V SOT-223
- Datasheet Download
- NIF62514T3G.pdf
Availability of NIF62514T3G
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of NIF62514T3G, we specialize in ON Semiconductor all series electronic components. NIF62514T3G can be shipped within 24 hours after order. If you have any demands for NIF62514T3G, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- NIF62514T3G Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
NIF62514T3G
| Internal Part Number | EIS-NIF62514T3G | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| PCN Design/Specification | Datasheet MSL Updated 2/April/2007 | |
| Standard Package | 4,000 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Power Distribution Switches, Load Drivers | |
| Series | HDPlus™ | |
| Packaging | Tape & Reel (TR) | |
| Switch Type | General Purpose | |
| Number of Outputs | 1 | |
| Ratio - Input:Output | 1:1 | |
| Output Configuration | Low Side | |
| Output Type | N-Channel | |
| Interface | On/Off | |
| Voltage - Load | 42V (Max) | |
| Voltage - Supply (Vcc/Vdd) | Not Required | |
| Current - Output (Max) | 6A | |
| Rds On (Typ) | 90 mOhm | |
| Input Type | Non-Inverting | |
| Features | Auto Restart, Slew Rate Controlled | |
| Fault Protection | Current Limiting (Fixed), Over Temperature, Over Voltage | |
| Operating Temperature | -55°C ~ 150°C (TJ) | |
| Package / Case | TO-261-4, TO-261AA | |
| Supplier Device Package | SOT-223 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | NIF62514T3G | |
| Related Links | NIF62, NIF62514T3G Datasheet, ON Semiconductor Distributor | |
NIF62514T3G Details Description
