Vishay Semiconductor/Diodes Division P4SMA56CAHE3/5A
- Mfg. Part Number
- P4SMA56CAHE3/5A
- Manufacturer
- Vishay Semiconductor/Diodes Division
- Product Category
- TVS - Diodes
- Brief Description
- TVS DIODE 47.8VWM 77VC DO-214AC
- Datasheet Download
- P4SMA56CAHE3/5A.pdf
Availability of P4SMA56CAHE3/5A
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.12137
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of P4SMA56CAHE3/5A, we specialize in Vishay Semiconductor/Diodes Division all series electronic components. P4SMA56CAHE3/5A can be shipped within 24 hours after order. If you have any demands for P4SMA56CAHE3/5A, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- P4SMA56CAHE3/5A Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
P4SMA56CAHE3/5A
| Internal Part Number | EIS-P4SMA56CAHE3/5A | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 7,500 | |
| Category | Circuit Protection | |
| Family | TVS - Diodes | |
| Series | Automotive, AEC-Q101, P4SMA, TransZorb® | |
| Packaging | Tape & Reel (TR) | |
| Type | Zener | |
| Unidirectional Channels | - | |
| Bidirectional Channels | 1 | |
| Voltage - Reverse Standoff (Typ) | 47.8V | |
| Voltage - Breakdown (Min) | 53.2V | |
| Voltage - Clamping (Max) @ Ipp | 77V | |
| Current - Peak Pulse (10/1000µs) | 5.2A | |
| Power - Peak Pulse | 400W | |
| Power Line Protection | No | |
| Applications | Automotive | |
| Capacitance @ Frequency | - | |
| Operating Temperature | -65°C ~ 150°C (TJ) | |
| Mounting Type | Surface Mount | |
| Package / Case | DO-214AC, SMA | |
| Supplier Device Package | DO-214AC (SMA) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | P4SMA56CAHE3/5A | |
| Related Links | P4SMA56, P4SMA56CAHE3/5A Datasheet, Vishay Semiconductor/Diodes Division Distributor | |
P4SMA56CAHE3/5A Details Description
