TDK-Lambda Americas, Inc. PH75F110-12
- Mfg. Part Number
- PH75F110-12
- Manufacturer
- TDK-Lambda Americas, Inc.
- Product Category
- DC DC Converters
- Brief Description
- CONVERT DC-DC 12V 75W 6.3A
- Datasheet Download
- PH75F110-12.pdf
Availability of PH75F110-12
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 129.05000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of PH75F110-12, we specialize in TDK-Lambda Americas, Inc. all series electronic components. PH75F110-12 can be shipped within 24 hours after order. If you have any demands for PH75F110-12, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- PH75F110-12 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
PH75F110-12
| Internal Part Number | EIS-PH75F110-12 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| PCN Obsolescence/ EOL | SWS50-600, SWS300A, PH-S, PH-F 01/Oct/2015 | |
| Standard Package | 1 | |
| Category | Power Supplies - Board Mount | |
| Family | DC DC Converters | |
| Series | PH-F | |
| Packaging | Bulk | |
| Type | Isolated Module | |
| Number of Outputs | 1 | |
| Voltage - Input (Min) | 82V | |
| Voltage - Input (Max) | 185V | |
| Voltage - Output 1 | 12V | |
| Voltage - Output 2 | - | |
| Voltage - Output 3 | - | |
| Current - Output (Max) | 6.3A | |
| Power (Watts) - Manufacture Series | 75W | |
| Voltage - Isolation | 3kV (3000V) | |
| Features | Remote On/Off, OCP, OVP | |
| Mounting Type | Through Hole | |
| Package / Case | Module | |
| Size / Dimension | 3.39" L x 2.44" W x 0.50" H (86.0mm x 62.0mm x 12.7mm) | |
| Operating Temperature | -20°C ~ 85°C | |
| Efficiency | - | |
| Power (Watts) - Max | 75W | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | PH75F110-12 | |
| Related Links | PH75F, PH75F110-12 Datasheet, TDK-Lambda Americas, Inc. Distributor | |
