NXP Semiconductors/Freescale Semiconductor, Inc. PHP225,118
- Mfg. Part Number
- PHP225,118
- Manufacturer
- NXP Semiconductors/Freescale Semiconductor, Inc.
- Product Category
- FETs - Arrays
- Brief Description
- MOSFET 2P-CH 30V 2.3A 8SOIC
- Datasheet Download
- PHP225,118.pdf
Availability of PHP225,118
Available Quantity
12520 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.31920
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of PHP225,118, we specialize in NXP Semiconductors/Freescale Semiconductor, Inc. all series electronic components. PHP225,118 can be shipped within 24 hours after order. If you have any demands for PHP225,118, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- PHP225,118 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
PHP225,118
| Internal Part Number | EIS-PHP225,118 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| PCN Packaging | Lighter Packing Reels 30/Mar/2014 | |
| Standard Package | 2,500 | |
| Category | Discrete Semiconductor Products | |
| Family | FETs - Arrays | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| FET Type | 2 P-Channel (Dual) | |
| FET Feature | Logic Level Gate | |
| Drain to Source Voltage (Vdss) | 30V | |
| Current - Continuous Drain (Id) @ 25°C | 2.3A | |
| Rds On (Max) @ Id, Vgs | 250 mOhm @ 1A, 10V | |
| Vgs(th) (Max) @ Id | 2.8V @ 1mA | |
| Gate Charge (Qg) @ Vgs | 25nC @ 10V | |
| Input Capacitance (Ciss) @ Vds | 250pF @ 20V | |
| Power - Max | 2W | |
| Mounting Type | Surface Mount | |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) | |
| Supplier Device Package | 8-SO | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | PHP225,118 | |
| Related Links | PHP22, PHP225,118 Datasheet, NXP Semiconductors/Freescale Semiconductor, Inc. Distributor | |
PHP225,118 Details Description
