Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
Internal Part Number | EIS-PI74FCT374ATQE | |
Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
Production Status (Lifecycle) | Obsolete / Discontinued | |
Condition | New & Unused, Original Sealed | |
PCN Obsolescence/ EOL | Multiple Devices 11/Feb/2008 Multiple Devices 11/Feb/2008 | |
EDA / CAD Models | Download from Accelerated Designs | |
Standard Package | 55 | |
Category | Integrated Circuits (ICs) | |
Family | Logic - Flip Flops | |
Series | 74FCT | |
Packaging | Tube | |
Function | Standard | |
Type | D-Type | |
Output Type | Tri-State, Non-Inverted | |
Number of Elements | 1 | |
Number of Bits per Element | 8 | |
Frequency - Clock | - | |
Max Propagation Delay @ V, Max CL | 6.5ns @ 5V, 50pF | |
Trigger Type | Positive Edge | |
Current - Output High, Low | 15mA, 64mA | |
Voltage - Supply | 4.75 V ~ 5.25 V | |
Current - Quiescent | 500µA | |
Input Capacitance | 6pF | |
Operating Temperature | -40°C ~ 85°C (TA) | |
Mounting Type | Surface Mount | |
Package / Case | 20-SSOP (0.154", 3.90mm Width) | |
Weight | 0.001 KG | |
Application | Email for details | |
Alternative Part (Replacement) | PI74FCT374ATQE | |
Related Links | PI74FCT, PI74FCT374ATQE Datasheet, Pericom Semiconductor Corp. Distributor |
