Murata Electronics North America PLA10AS1522R0R2B
- Mfg. Part Number
- PLA10AS1522R0R2B
- Manufacturer
- Murata Electronics North America
- Product Category
- Common Mode Chokes
- Brief Description
- COMMON MODE CHOKE 1.5MH 2A T/H
- Datasheet Download
- PLA10AS1522R0R2B.pdf
Availability of PLA10AS1522R0R2B
Available Quantity
5776 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.70990
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of PLA10AS1522R0R2B, we specialize in Murata Electronics North America all series electronic components. PLA10AS1522R0R2B can be shipped within 24 hours after order. If you have any demands for PLA10AS1522R0R2B, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- PLA10AS1522R0R2B Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
PLA10AS1522R0R2B
| Internal Part Number | EIS-PLA10AS1522R0R2B | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1,260 | |
| Category | Filters | |
| Family | Common Mode Chokes | |
| Series | EMIFIL®, PLA10 | |
| Packaging | Bulk | |
| Filter Type | Power Line | |
| Number of Lines | 2 | |
| Inductance | 1.5mH | |
| Current | 2A | |
| DC Resistance (DCR) | - | |
| Impedance | - | |
| Operating Temperature | -25°C ~ 60°C | |
| Mounting Type | Through Hole | |
| Size / Dimension | 0.709" L x 0.630" W (18.00mm x 16.00mm) | |
| Height (Max) | 0.689" (17.50mm) | |
| Package / Case | Vertical, 4 PC Pin | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | PLA10AS1522R0R2B | |
| Related Links | PLA10AS1, PLA10AS1522R0R2B Datasheet, Murata Electronics North America Distributor | |
PLA10AS1522R0R2B Details Description
