Vishay Thin Film PLT1206Z2232LBTS
- Mfg. Part Number
- PLT1206Z2232LBTS
- Manufacturer
- Vishay Thin Film
- Product Category
- Chip Resistor - Surface Mount
- Brief Description
- RES SMD 22.3KOHM 0.01% 0.4W 1206
- Datasheet Download
- PLT1206Z2232LBTS.pdf
Availability of PLT1206Z2232LBTS
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 6.75200
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of PLT1206Z2232LBTS, we specialize in Vishay Thin Film all series electronic components. PLT1206Z2232LBTS can be shipped within 24 hours after order. If you have any demands for PLT1206Z2232LBTS, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- PLT1206Z2232LBTS Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
PLT1206Z2232LBTS
| Internal Part Number | EIS-PLT1206Z2232LBTS | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| PCN Assembly/Origin | PLT Low TCR 20/Nov/2014 | |
| Standard Package | 1 | |
| Category | Resistors | |
| Family | Chip Resistor - Surface Mount | |
| Series | PLT | |
| Packaging | Tape & Reel (TR) | |
| Resistance (Ohms) | 22.3k | |
| Tolerance | ±0.01% | |
| Power (Watts) | 0.4W | |
| Composition | Thin Film | |
| Features | Anti-Corrosive, Flame Proof, Moisture Resistant, Safety | |
| Temperature Coefficient | ±5ppm/°C | |
| Operating Temperature | -55°C ~ 125°C | |
| Package / Case | 1206 (3216 Metric) | |
| Supplier Device Package | 1206 | |
| Size / Dimension | 0.126" L x 0.063" W (3.20mm x 1.60mm) | |
| Height | 0.033" (0.84mm) | |
| Number of Terminations | 2 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | PLT1206Z2232LBTS | |
| Related Links | PLT1206Z, PLT1206Z2232LBTS Datasheet, Vishay Thin Film Distributor | |
PLT1206Z2232LBTS Details Description
