E-Switch PV4F2Y0SS-3G4
- Mfg. Part Number
- PV4F2Y0SS-3G4
- Manufacturer
- E-Switch
- Product Category
- Pushbutton Switches
- Brief Description
- SWITCH PUSHBUTTON DPST 2A 48V
- Datasheet Download
- PV4F2Y0SS-3G4.pdf
Availability of PV4F2Y0SS-3G4
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 20.42600
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of PV4F2Y0SS-3G4, we specialize in E-Switch all series electronic components. PV4F2Y0SS-3G4 can be shipped within 24 hours after order. If you have any demands for PV4F2Y0SS-3G4, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- PV4F2Y0SS-3G4 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
PV4F2Y0SS-3G4
| Internal Part Number | EIS-PV4F2Y0SS-3G4 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| RoHS Information | Switches RoHS Cert of Compliance | |
| 3D Model | PV4F2x0xx-3xx.stp | |
| Standard Package | 1 | |
| Category | Switches | |
| Family | Pushbutton Switches | |
| Series | PV4, LAMB | |
| Packaging | Bulk | |
| Type | Vandal Resistant, Illuminated | |
| Circuit | DPST (1-NO, 1-NC) | |
| Switch Function | On-Mom, Off-Mom | |
| Current Rating | 2A (DC) | |
| Voltage Rating - AC | - | |
| Voltage Rating - DC | 48V | |
| Actuator Type | Round, Button, Flush | |
| Color - Actuator/Cap | Silver | |
| Illumination Type, Color | LED, Red/Green | |
| Illumination Voltage (Nominal) | 12 VDC | |
| Mounting Type | Panel Mount, Front | |
| Termination Style | Solder, Quick Connect - 0.110" (2.8mm) | |
| Ingress Protection | IP65 - Dust Tight, Water Resistant | |
| Features | - | |
| Panel Cutout Dimensions | Circular - 19.00mm Dia | |
| Operating Temperature | -20°C ~ 55°C | |
| Mechanical Life | 1,000,000 Cycles | |
| Electrical Life | 50,000 Cycles | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | PV4F2Y0SS-3G4 | |
| Related Links | PV4F2Y, PV4F2Y0SS-3G4 Datasheet, E-Switch Distributor | |
