CUI Inc. PYB20-Q48-D12-H-U
- Mfg. Part Number
- PYB20-Q48-D12-H-U
- Manufacturer
- CUI Inc.
- Product Category
- DC DC Converters
- Brief Description
- DC/DC CONVERTER +/-12V 20W UFRM
- Datasheet Download
- PYB20-Q48-D12-H-U.pdf
Availability of PYB20-Q48-D12-H-U
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 53.23781
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of PYB20-Q48-D12-H-U, we specialize in CUI Inc. all series electronic components. PYB20-Q48-D12-H-U can be shipped within 24 hours after order. If you have any demands for PYB20-Q48-D12-H-U, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- PYB20-Q48-D12-H-U Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
PYB20-Q48-D12-H-U
| Internal Part Number | EIS-PYB20-Q48-D12-H-U | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Reliability Considerations for Power Supplies Power Supply Safety Standards, Agencies and Marks | |
| RoHS Information | PYB20-U Series Cert of Compliance | |
| Standard Package | 32 | |
| Category | Power Supplies - External/Internal (Off-Board) | |
| Family | DC DC Converters | |
| Series | PYB20-U | |
| Packaging | Bulk | |
| Type | Isolated | |
| Voltage - Input | 18 ~ 75 V | |
| Output | ±12V | |
| Number of Outputs | 2 | |
| Output - 1 @ Current (Max) | 12 VDC @ 834mA | |
| Output - 2 @ Current (Max) | -12 VDC @ 834mA | |
| Output - 3 @ Current (Max) | - | |
| Output - 4 @ Current (Max) | - | |
| Power (Watts) | 20W | |
| Applications | * | |
| Mounting Type | Chassis Mount | |
| Operating Temperature | -40°C ~ 85°C | |
| Efficiency | 88% | |
| Package / Case | Module | |
| Size / Dimension | 2.99" L x 1.24" W x 0.99" H (76.0mm x 31.5mm x 25.1mm) | |
| Power (Watts) - Max | 20W | |
| Approvals | EN, IEC | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | PYB20-Q48-D12-H-U | |
| Related Links | PYB20-Q4, PYB20-Q48-D12-H-U Datasheet, CUI Inc. Distributor | |
PYB20-Q48-D12-H-U Details Description
