Texas Instruments REF102CP
- Mfg. Part Number
- REF102CP
- Manufacturer
- Texas Instruments
- Product Category
- PMIC - Voltage Reference
- Brief Description
- IC VREF SERIES 10V 8DIP
- Datasheet Download
- REF102CP.pdf
Availability of REF102CP
Available Quantity
5388 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 5.45625
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of REF102CP, we specialize in Texas Instruments all series electronic components. REF102CP can be shipped within 24 hours after order. If you have any demands for REF102CP, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- REF102CP Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
REF102CP
| Internal Part Number | EIS-REF102CP | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 50 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Voltage Reference | |
| Series | - | |
| Packaging | Tube | |
| Reference Type | Series | |
| Output Type | Fixed | |
| Voltage - Output (Min/Fixed) | 10V | |
| Voltage - Output (Max) | - | |
| Current - Output | 10mA | |
| Tolerance | ±0.025% | |
| Temperature Coefficient | 2.5ppm/°C | |
| Noise - 0.1Hz to 10Hz | 5µVp-p | |
| Noise - 10Hz to 10kHz | - | |
| Voltage - Input | 11.4 V ~ 36 V | |
| Current - Supply | 1.4mA | |
| Current - Cathode | - | |
| Operating Temperature | -25°C ~ 85°C (TA) | |
| Mounting Type | Through Hole | |
| Package / Case | 8-DIP (0.300", 7.62mm) | |
| Supplier Device Package | 8-PDIP | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | REF102CP | |
| Related Links | REF1, REF102CP Datasheet, Texas Instruments Distributor | |
REF102CP Details Description
