Texas Instruments REG710NA-5/250G4
- Mfg. Part Number
- REG710NA-5/250G4
- Manufacturer
- Texas Instruments
- Product Category
- PMIC - Voltage Regulators - DC DC Switching Regulators
- Brief Description
- IC REG SWTCHD CAP 5V 30MA SOT23
- Datasheet Download
- REG710NA-5/250G4.pdf
Availability of REG710NA-5/250G4
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.82651
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of REG710NA-5/250G4, we specialize in Texas Instruments all series electronic components. REG710NA-5/250G4 can be shipped within 24 hours after order. If you have any demands for REG710NA-5/250G4, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- REG710NA-5/250G4 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
REG710NA-5/250G4
| Internal Part Number | EIS-REG710NA-5/250G4 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 250 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Voltage Regulators - DC DC Switching Regulators | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Function | Step-Up/Step-Down | |
| Output Configuration | Positive | |
| Topology | Charge Pump | |
| Output Type | Fixed | |
| Number of Outputs | 1 | |
| Voltage - Input (Min) | 2.7V | |
| Voltage - Input (Max) | 5.5V | |
| Voltage - Output (Min/Fixed) | 5V | |
| Voltage - Output (Max) | - | |
| Current - Output | 30mA | |
| Frequency - Switching | 1MHz | |
| Synchronous Rectifier | No | |
| Operating Temperature | -40°C ~ 85°C (TA) | |
| Mounting Type | Surface Mount | |
| Package / Case | SOT-23-6 | |
| Supplier Device Package | SOT-23-6 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | REG710NA-5/250G4 | |
| Related Links | REG710NA, REG710NA-5/250G4 Datasheet, Texas Instruments Distributor | |
REG710NA-5/250G4 Details Description
