Susumu RG1005N-6980-C-T10
- Mfg. Part Number
- RG1005N-6980-C-T10
- Manufacturer
- Susumu
- Product Category
- Chip Resistor - Surface Mount
- Brief Description
- RES SMD 698 OHM 0.25% 1/16W 0402
- Datasheet Download
- RG1005N-6980-C-T10.pdf
Availability of RG1005N-6980-C-T10
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of RG1005N-6980-C-T10, we specialize in Susumu all series electronic components. RG1005N-6980-C-T10 can be shipped within 24 hours after order. If you have any demands for RG1005N-6980-C-T10, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- RG1005N-6980-C-T10 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
RG1005N-6980-C-T10
| Internal Part Number | EIS-RG1005N-6980-C-T10 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| RoHS Information | Cert of RoHS Compliance | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 10,000 | |
| Category | Resistors | |
| Family | Chip Resistor - Surface Mount | |
| Series | RG | |
| Packaging | Tape & Reel (TR) | |
| Resistance (Ohms) | 698 | |
| Tolerance | ±0.25% | |
| Power (Watts) | 0.063W, 1/16W | |
| Composition | Thin Film | |
| Features | Automotive AEC-Q200 | |
| Temperature Coefficient | ±10ppm/°C | |
| Operating Temperature | -55°C ~ 155°C | |
| Package / Case | 0402 (1005 Metric) | |
| Supplier Device Package | 0402 | |
| Size / Dimension | 0.039" L x 0.020" W (1.00mm x 0.50mm) | |
| Height | 0.016" (0.40mm) | |
| Number of Terminations | 2 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | RG1005N-6980-C-T10 | |
| Related Links | RG1005N-6, RG1005N-6980-C-T10 Datasheet, Susumu Distributor | |
RG1005N-6980-C-T10 Details Description
