LEMO RGJ.1B.305.CLL
- Mfg. Part Number
- RGJ.1B.305.CLL
- Manufacturer
- LEMO
- Product Category
- Coaxial Connectors (RF) - Adapters
- Brief Description
- CONN ADAPT PLUG TO JACK
- Datasheet Download
- RGJ.1B.305.CLL.pdf
Availability of RGJ.1B.305.CLL
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 64.71000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of RGJ.1B.305.CLL, we specialize in LEMO all series electronic components. RGJ.1B.305.CLL can be shipped within 24 hours after order. If you have any demands for RGJ.1B.305.CLL, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- RGJ.1B.305.CLL Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
RGJ.1B.305.CLL
| Internal Part Number | EIS-RGJ.1B.305.CLL | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Connectors, Interconnects | |
| Family | Coaxial Connectors (RF) - Adapters | |
| Series | - | |
| Packaging | Bulk | |
| Adapter Type | Plug to Jack | |
| Adapter Series | NIM-CAMAC CD/N 549 to NIM-CAMAC CD/N 549 | |
| Center Gender | Female to Male | |
| Convert From (Adapter End) | NIM-CAMAC CD/N 549 Plug, Male Pin | |
| Convert To (Adapter End) | NIM-CAMAC CD/N 549 Jack, Female Socket | |
| Conversion Type | Same Series | |
| Impedance | - | |
| Style | Straight | |
| Mounting Type | Panel Mount, Bulkhead | |
| Frequency - Max | - | |
| Ingress Protection | IP50 - Dust Protected | |
| Features | - | |
| Body Material | Brass | |
| Body Finish | Chrome | |
| Dielectric Material | Polyetheretherketone (PEEK) | |
| Center Contact Material | - | |
| Center Contact Plating | Gold | |
| Mating Cycles | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | RGJ.1B.305.CLL | |
| Related Links | RGJ.1B., RGJ.1B.305.CLL Datasheet, LEMO Distributor | |
