Toshiba Semiconductor & Storage RN1108CT(TPL3)
- Mfg. Part Number
- RN1108CT(TPL3)
- Manufacturer
- Toshiba Semiconductor & Storage
- Product Category
- Transistors (BJT) - Single, Pre-Biased
- Brief Description
- TRANS PREBIAS NPN 0.05W CST3
- Datasheet Download
- RN1108CT(TPL3).pdf
Availability of RN1108CT(TPL3)
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.04960
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of RN1108CT(TPL3), we specialize in Toshiba Semiconductor & Storage all series electronic components. RN1108CT(TPL3) can be shipped within 24 hours after order. If you have any demands for RN1108CT(TPL3), Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- RN1108CT(TPL3) Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
RN1108CT(TPL3)
| Internal Part Number | EIS-RN1108CT(TPL3) | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 10,000 | |
| Category | Discrete Semiconductor Products | |
| Family | Transistors (BJT) - Single, Pre-Biased | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Transistor Type | NPN - Pre-Biased | |
| Current - Collector (Ic) (Max) | 50mA | |
| Voltage - Collector Emitter Breakdown (Max) | 20V | |
| Resistor - Base (R1) (Ohms) | 22k | |
| Resistor - Emitter Base (R2) (Ohms) | 47k | |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 120 @ 10mA, 5V | |
| Vce Saturation (Max) @ Ib, Ic | 150mV @ 250µA, 5mA | |
| Current - Collector Cutoff (Max) | 500nA | |
| Frequency - Transition | - | |
| Power - Max | 50mW | |
| Mounting Type | Surface Mount | |
| Package / Case | SC-101, SOT-883 | |
| Supplier Device Package | CST3 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | RN1108CT(TPL3) | |
| Related Links | RN1108C, RN1108CT(TPL3) Datasheet, Toshiba Semiconductor & Storage Distributor | |
RN1108CT(TPL3) Details Description
