JST Sales America Inc. S12B-ZR-SM3A-TF
- Mfg. Part Number
- S12B-ZR-SM3A-TF
- Manufacturer
- JST Sales America Inc.
- Product Category
- Rectangular Connectors - Headers, Male Pins
- Brief Description
- CONN HEADER ZH SIDE 12POS 1.5MM
- Datasheet Download
- S12B-ZR-SM3A-TF.pdf
Availability of S12B-ZR-SM3A-TF
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of S12B-ZR-SM3A-TF, we specialize in JST Sales America Inc. all series electronic components. S12B-ZR-SM3A-TF can be shipped within 24 hours after order. If you have any demands for S12B-ZR-SM3A-TF, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- S12B-ZR-SM3A-TF Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
S12B-ZR-SM3A-TF
| Internal Part Number | EIS-S12B-ZR-SM3A-TF | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1,000 | |
| Category | Connectors, Interconnects | |
| Family | Rectangular Connectors - Headers, Male Pins | |
| Series | ZH | |
| Packaging | Tape & Reel (TR) | |
| Contact Type | Male Pin | |
| Connector Type | Header, Shrouded | |
| Number of Positions | 12 | |
| Number of Positions Loaded | All | |
| Pitch | 0.059" (1.50mm) | |
| Number of Rows | 1 | |
| Row Spacing | - | |
| Contact Mating Length | - | |
| Mounting Type | Surface Mount, Right Angle | |
| Termination | Solder | |
| Fastening Type | Detent Lock | |
| Features | Solder Retention | |
| Contact Finish | Tin-Lead | |
| Contact Finish Thickness | - | |
| Color | Natural | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | S12B-ZR-SM3A-TF | |
| Related Links | S12B-ZR, S12B-ZR-SM3A-TF Datasheet, JST Sales America Inc. Distributor | |
S12B-ZR-SM3A-TF Details Description
