Semtech SC4520SETRT
- Mfg. Part Number
- SC4520SETRT
- Manufacturer
- Semtech
- Product Category
- PMIC - Voltage Regulators - DC DC Switching Regulators
- Brief Description
- IC REG BUCK ADJ 3A 8SOIC
- Datasheet Download
- SC4520SETRT.pdf
Availability of SC4520SETRT
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.50583
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of SC4520SETRT, we specialize in Semtech all series electronic components. SC4520SETRT can be shipped within 24 hours after order. If you have any demands for SC4520SETRT, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- SC4520SETRT Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
SC4520SETRT
| Internal Part Number | EIS-SC4520SETRT | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 2,500 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Voltage Regulators - DC DC Switching Regulators | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Function | Step-Down | |
| Output Configuration | Positive | |
| Topology | Buck | |
| Output Type | Adjustable | |
| Number of Outputs | 1 | |
| Voltage - Input (Min) | 4.4V | |
| Voltage - Input (Max) | 24V | |
| Voltage - Output (Min/Fixed) | 0.8V | |
| Voltage - Output (Max) | 20.4V | |
| Current - Output | 3A | |
| Frequency - Switching | 100kHz ~ 600kHz | |
| Synchronous Rectifier | No | |
| Operating Temperature | -40°C ~ 125°C (TA) | |
| Mounting Type | Surface Mount | |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) Exposed Pad | |
| Supplier Device Package | 8-SOIC, EDP | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | SC4520SETRT | |
| Related Links | SC452, SC4520SETRT Datasheet, Semtech Distributor | |
