Bel Fuse Inc. SC54B-820
- Mfg. Part Number
- SC54B-820
- Manufacturer
- Bel Fuse Inc.
- Product Category
- Fixed Inductors
- Brief Description
- FIXED IND 82UH 700MA 600 MOHM
- Datasheet Download
- SC54B-820.pdf
Availability of SC54B-820
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.45814
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of SC54B-820, we specialize in Bel Fuse Inc. all series electronic components. SC54B-820 can be shipped within 24 hours after order. If you have any demands for SC54B-820, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- SC54B-820 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
SC54B-820
| Internal Part Number | EIS-SC54B-820 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| RoHS Information | RoHS Compliance | |
| Featured Product | SC Series SMD Power Inductors | |
| Standard Package | 1,000 | |
| Category | Inductors, Coils, Chokes | |
| Family | Fixed Inductors | |
| Series | SC54B | |
| Packaging | Tape & Reel (TR) | |
| Type | Wirewound | |
| Material - Core | - | |
| Inductance | 82µH | |
| Tolerance | ±20% | |
| Current Rating | 700mA | |
| Current - Saturation | 580mA | |
| Shielding | Unshielded | |
| DC Resistance (DCR) | 600 mOhm Max | |
| Q @ Freq | - | |
| Frequency - Self Resonant | - | |
| Operating Temperature | - | |
| Frequency - Test | 2.52MHz | |
| Mounting Type | Surface Mount | |
| Package / Case | Nonstandard | |
| Size / Dimension | 0.240" L x 0.220" W (6.10mm x 5.60mm) | |
| Height - Seated (Max) | 0.191" (4.85mm) | |
| Supplier Device Package | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | SC54B-820 | |
| Related Links | SC54, SC54B-820 Datasheet, Bel Fuse Inc. Distributor | |
