NKK Switches SCB15P10C-4GA
- Mfg. Part Number
- SCB15P10C-4GA
- Manufacturer
- NKK Switches
- Product Category
- Pushbutton Switches
- Brief Description
- SWITCH PUSHBUTTON SPDT 10A 125V
- Datasheet Download
- SCB15P10C-4GA.pdf
Availability of SCB15P10C-4GA
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 12.02000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of SCB15P10C-4GA, we specialize in NKK Switches all series electronic components. SCB15P10C-4GA can be shipped within 24 hours after order. If you have any demands for SCB15P10C-4GA, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- SCB15P10C-4GA Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
SCB15P10C-4GA
| Internal Part Number | EIS-SCB15P10C-4GA | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Featured Product | Pushbutton Switches | |
| Standard Package | 1 | |
| Category | Switches | |
| Family | Pushbutton Switches | |
| Series | SCB | |
| Packaging | Bulk | |
| Type | Standard | |
| Circuit | SPDT | |
| Switch Function | On-Mom | |
| Current Rating | 10A (AC) | |
| Voltage Rating - AC | 125V | |
| Voltage Rating - DC | - | |
| Actuator Type | Round, Button | |
| Color - Actuator/Cap | Blue | |
| Illumination Type, Color | - | |
| Illumination Voltage (Nominal) | - | |
| Mounting Type | Panel Mount, Rear | |
| Termination Style | Screw Terminal | |
| Ingress Protection | - | |
| Features | With Shroud | |
| Panel Cutout Dimensions | Circular - 12.50mm Dia | |
| Operating Temperature | -40°C ~ 85°C | |
| Mechanical Life | 1,000,000 Cycles | |
| Electrical Life | 50,000 Cycles | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | SCB15P10C-4GA | |
| Related Links | SCB15P, SCB15P10C-4GA Datasheet, NKK Switches Distributor | |
SCB15P10C-4GA Details Description
