Silicon Labs SI8455BA-B-IS
- Mfg. Part Number
- SI8455BA-B-IS
- Manufacturer
- Silicon Labs
- Product Category
- Digital Isolators
- Brief Description
- DGTL ISO 1KV 5CH GEN PURP 16SOIC
- Datasheet Download
- SI8455BA-B-IS.pdf
Availability of SI8455BA-B-IS
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 2.69671
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of SI8455BA-B-IS, we specialize in Silicon Labs all series electronic components. SI8455BA-B-IS can be shipped within 24 hours after order. If you have any demands for SI8455BA-B-IS, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- SI8455BA-B-IS Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
SI8455BA-B-IS
| Internal Part Number | EIS-SI8455BA-B-IS | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Video File | Digital Isolation Overview Digital Isolators vs. Optocouplers | |
| Standard Package | 46 | |
| Category | Isolators | |
| Family | Digital Isolators | |
| Series | ISOpro | |
| Packaging | Tube | |
| Technology | Capacitive Coupling | |
| Type | General Purpose | |
| Isolated Power | No | |
| Number of Channels | 5 | |
| Inputs - Side 1/Side 2 | 5/0 | |
| Channel Type | Unidirectional | |
| Voltage - Isolation | 1000Vrms | |
| Common Mode Transient Immunity (Min) | 25kV/µs (Typ) | |
| Data Rate | 150Mbps | |
| Propagation Delay tpLH / tpHL (Max) | 9.5ns, 9.5ns | |
| Pulse Width Distortion (Max) | 2.5ns | |
| Rise / Fall Time (Typ) | 3.8ns, 2.8ns | |
| Voltage - Supply | 2.7 V ~ 5.5 V | |
| Operating Temperature | -40°C ~ 125°C | |
| Package / Case | 16-SOIC (0.154", 3.90mm Width) | |
| Supplier Device Package | 16-SOIC | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | SI8455BA-B-IS | |
| Related Links | SI8455, SI8455BA-B-IS Datasheet, Silicon Labs Distributor | |
SI8455BA-B-IS Details Description
