Amphenol Aerospace Operations SJTG06RT-18-11P(014)
- Mfg. Part Number
- SJTG06RT-18-11P(014)
- Manufacturer
- Amphenol Aerospace Operations
- Product Category
- Circular Connectors
- Brief Description
- CONN PLUG 11POS STRAIGHT PINS
- Datasheet Download
- SJTG06RT-18-11P(014).pdf
Availability of SJTG06RT-18-11P(014)
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 557.58920
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of SJTG06RT-18-11P(014), we specialize in Amphenol Aerospace Operations all series electronic components. SJTG06RT-18-11P(014) can be shipped within 24 hours after order. If you have any demands for SJTG06RT-18-11P(014), Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- SJTG06RT-18-11P(014) Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
SJTG06RT-18-11P(014)
| Internal Part Number | EIS-SJTG06RT-18-11P(014) | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Connectors, Interconnects | |
| Family | Circular Connectors | |
| Series | MIL-DTL-38999 I & III, VG 96912, SJT | |
| Packaging | Bulk | |
| Connector Type | Plug, Male Pins | |
| Number of Positions | 11 | |
| Shell Size - Insert | 18-11 | |
| Shell Size, MIL | - | |
| Mounting Type | Free Hanging (In-Line) | |
| Termination | Crimp | |
| Fastening Type | Bayonet Lock | |
| Orientation | N (Normal) | |
| Ingress Protection | Environment Resistant | |
| Shell Material, Finish | Aluminum, Olive Drab Cadmium Plated | |
| Contact Finish | Gold | |
| Features | Shielded | |
| Contact Finish Thickness | 50µin (1.27µm) | |
| Current Rating | - | |
| Voltage - Rated | 900VAC, 1250VDC | |
| Operating Temperature | -65°C ~ 175°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | SJTG06RT-18-11P(014) | |
| Related Links | SJTG06RT-1, SJTG06RT-18-11P(014) Datasheet, Amphenol Aerospace Operations Distributor | |
