Littelfuse SLD14U-017
- Mfg. Part Number
- SLD14U-017
- Manufacturer
- Littelfuse
- Product Category
- TVS - Diodes
- Brief Description
- TVS DIODE 14VWM 23.2VC AXIAL
- Datasheet Download
- SLD14U-017.pdf
Availability of SLD14U-017
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.51800
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of SLD14U-017, we specialize in Littelfuse all series electronic components. SLD14U-017 can be shipped within 24 hours after order. If you have any demands for SLD14U-017, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- SLD14U-017 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
SLD14U-017
| Internal Part Number | EIS-SLD14U-017 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Transient Voltage Suppression (TVS) Diodes | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 800 | |
| Category | Circuit Protection | |
| Family | TVS - Diodes | |
| Series | Automotive, AEC-Q101, SLD | |
| Packaging | Tape & Reel (TR) | |
| Type | Zener | |
| Unidirectional Channels | 1 | |
| Bidirectional Channels | - | |
| Voltage - Reverse Standoff (Typ) | 14V | |
| Voltage - Breakdown (Min) | 15.6V | |
| Voltage - Clamping (Max) @ Ipp | 23.2V | |
| Current - Peak Pulse (10/1000µs) | 219.8A | |
| Power - Peak Pulse | 5000W (5kW) | |
| Power Line Protection | No | |
| Applications | Automotive | |
| Capacitance @ Frequency | - | |
| Operating Temperature | -55°C ~ 175°C (TJ) | |
| Mounting Type | Through Hole | |
| Package / Case | P600, Axial | |
| Supplier Device Package | P600 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | SLD14U-017 | |
| Related Links | SLD14, SLD14U-017 Datasheet, Littelfuse Distributor | |
