Diodes Incorporated SMBJ8.0A-13
- Mfg. Part Number
- SMBJ8.0A-13
- Manufacturer
- Diodes Incorporated
- Product Category
- TVS - Diodes
- Brief Description
- TVS DIODE 8VWM 13.6VC SMB
- Datasheet Download
- SMBJ8.0A-13.pdf
Availability of SMBJ8.0A-13
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of SMBJ8.0A-13, we specialize in Diodes Incorporated all series electronic components. SMBJ8.0A-13 can be shipped within 24 hours after order. If you have any demands for SMBJ8.0A-13, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- SMBJ8.0A-13 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
SMBJ8.0A-13
| Internal Part Number | EIS-SMBJ8.0A-13 | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 3,000 | |
| Category | Circuit Protection | |
| Family | TVS - Diodes | |
| Series | SMBJ | |
| Packaging | Tape & Reel (TR) | |
| Type | Zener | |
| Unidirectional Channels | 1 | |
| Bidirectional Channels | - | |
| Voltage - Reverse Standoff (Typ) | 8V | |
| Voltage - Breakdown (Min) | 8.89V | |
| Voltage - Clamping (Max) @ Ipp | 13.6V | |
| Current - Peak Pulse (10/1000µs) | 44.1A | |
| Power - Peak Pulse | 600W | |
| Power Line Protection | No | |
| Applications | General Purpose | |
| Capacitance @ Frequency | - | |
| Operating Temperature | -55°C ~ 150°C (TJ) | |
| Mounting Type | Surface Mount | |
| Package / Case | DO-214AA, SMB | |
| Supplier Device Package | SMB | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | SMBJ8.0A-13 | |
| Related Links | SMBJ8, SMBJ8.0A-13 Datasheet, Diodes Incorporated Distributor | |
