Cornell Dubilier Electronics SPSX561M02R-4
- Mfg. Part Number
- SPSX561M02R-4
- Manufacturer
- Cornell Dubilier Electronics
- Product Category
- Aluminum - Polymer Capacitors
- Brief Description
- CAP POLYMER 560UF 20% 2V SMD
- Datasheet Download
- SPSX561M02R-4.pdf
Availability of SPSX561M02R-4
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of SPSX561M02R-4, we specialize in Cornell Dubilier Electronics all series electronic components. SPSX561M02R-4 can be shipped within 24 hours after order. If you have any demands for SPSX561M02R-4, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- SPSX561M02R-4 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
SPSX561M02R-4
| Internal Part Number | EIS-SPSX561M02R-4 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| PCN Obsolescence/ EOL | SPCX, SPSX Devices 30/Nov/2014 SPCX SPSX Series EOL 30/Nov/2014 | |
| Standard Package | 3,500 | |
| Category | Capacitors | |
| Family | Aluminum - Polymer Capacitors | |
| Series | SPSX | |
| Packaging | Tape & Reel (TR) | |
| Capacitance | 560µF | |
| Tolerance | ±20% | |
| Voltage Rating | 2V | |
| ESR (Equivalent Series Resistance) | 4.5 mOhm | |
| Lifetime @ Temp. | 1000 Hrs @ 105°C | |
| Operating Temperature | -40°C ~ 105°C | |
| Type | Polymer | |
| Applications | General Purpose | |
| Ripple Current | 4A | |
| Impedance | - | |
| Lead Spacing | - | |
| Size / Dimension | 0.287" L x 0.169" W (7.30mm x 4.30mm) | |
| Height - Seated (Max) | 0.083" (2.10mm) | |
| Surface Mount Land Size | - | |
| Mounting Type | Surface Mount | |
| Package / Case | 2917 (7343 Metric) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | SPSX561M02R-4 | |
| Related Links | SPSX56, SPSX561M02R-4 Datasheet, Cornell Dubilier Electronics Distributor | |
SPSX561M02R-4 Details Description
