JAE Electronics SRCN1A25-16S
- Mfg. Part Number
- SRCN1A25-16S
- Manufacturer
- JAE Electronics
- Product Category
- Circular Connectors
- Brief Description
- CONN RECEPT 16POS W/SOCKETS
- Datasheet Download
- SRCN1A25-16S.pdf
Availability of SRCN1A25-16S
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 9.45000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of SRCN1A25-16S, we specialize in JAE Electronics all series electronic components. SRCN1A25-16S can be shipped within 24 hours after order. If you have any demands for SRCN1A25-16S, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- SRCN1A25-16S Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
SRCN1A25-16S
| Internal Part Number | EIS-SRCN1A25-16S | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 10 | |
| Category | Connectors, Interconnects | |
| Family | Circular Connectors | |
| Series | SRCN | |
| Packaging | Bulk | |
| Connector Type | Receptacle, Female Sockets | |
| Number of Positions | 16 | |
| Shell Size - Insert | 25-16 | |
| Shell Size, MIL | - | |
| Mounting Type | Free Hanging (In-Line) | |
| Termination | Solder Cup | |
| Fastening Type | Threaded | |
| Orientation | N (Normal) | |
| Ingress Protection | - | |
| Shell Material, Finish | Aluminum Alloy, Nickel Plated | |
| Contact Finish | Silver | |
| Features | Cable Clamp | |
| Contact Finish Thickness | - | |
| Current Rating | 10A | |
| Voltage - Rated | 250VAC, 350VDC | |
| Operating Temperature | -25°C ~ 85°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | SRCN1A25-16S | |
| Related Links | SRCN1A, SRCN1A25-16S Datasheet, JAE Electronics Distributor | |
