Sanken SWG030-12-C
- Mfg. Part Number
- SWG030-12-C
- Manufacturer
- Sanken
- Product Category
- AC DC Converters
- Brief Description
- AC/DC CONVERTER 12V 30W
- Datasheet Download
- SWG030-12-C.pdf
Availability of SWG030-12-C
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 47.68000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of SWG030-12-C, we specialize in Sanken all series electronic components. SWG030-12-C can be shipped within 24 hours after order. If you have any demands for SWG030-12-C, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- SWG030-12-C Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
SWG030-12-C
| Internal Part Number | EIS-SWG030-12-C | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 40 | |
| Category | Power Supplies - External/Internal (Off-Board) | |
| Family | AC DC Converters | |
| Series | SWG030 | |
| Type | Enclosed | |
| Number of Outputs | 1 | |
| Voltage - Input | 85 ~ 264 VAC | |
| Voltage - Output 1 | 12V | |
| Voltage - Output 2 | - | |
| Voltage - Output 3 | - | |
| Voltage - Output 4 | - | |
| Current - Output (Max) | 2.5A | |
| Power (Watts) | 30W | |
| Applications | ITE (Commercial) | |
| Voltage - Isolation | 3.0kV (3000V) | |
| Efficiency | 78% | |
| Operating Temperature | -10°C ~ 71°C (With Derating) | |
| Features | DC Input Capable, Universal Input | |
| Mounting Type | Chassis Mount | |
| Size / Dimension | 4.68" L x 3.07" W x 1.36" H (118.8mm x 78.0mm x 34.5mm) | |
| Minimum Load Required | - | |
| Approvals | CE, cURus, DEMKO | |
| Power (Watts) - Max | 30W | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | SWG030-12-C | |
| Related Links | SWG03, SWG030-12-C Datasheet, Sanken Distributor | |
SWG030-12-C Details Description
