ST TDA7565
.jpg)
- Mfg. Part Number
- TDA7565
- Manufacturer
- ST
- Product Category
- Linear - Amplifiers - Audio
- Brief Description
- IC AMP QUAD BCD/BRIDG FLEXIWATT2
- Datasheet Download
- TDA7565.pdf
Availability of TDA7565
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 9.97891
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of TDA7565, we specialize in ST all series electronic components. TDA7565 can be shipped within 24 hours after order. If you have any demands for TDA7565, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- TDA7565 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
TDA7565
| Internal Part Number | EIS-TDA7565 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Other Related Documents | TDA7565 View All Specifications | |
| Standard Package | 17 | |
| Category | Integrated Circuits (ICs) | |
| Family | Linear - Amplifiers - Audio | |
| Series | - | |
| Packaging | Tube | |
| Type | Class AB | |
| Output Type | 4-Channel (Quad) | |
| Max Output Power x Channels @ Load | 59W x 4 @ 4 Ohm | |
| Voltage - Supply | 8 V ~ 18 V | |
| Features | I²C, Mute, Short-Circuit and Thermal Protection, Standby | |
| Mounting Type | Through Hole | |
| Operating Temperature | -55°C ~ 150°C (TJ) | |
| Supplier Device Package | 27-Flexiwatt (Vertical) | |
| Package / Case | 27-Flexiwatt (Formed Leads) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | TDA7565 | |
| Related Links | TDA, TDA7565 Datasheet, ST Distributor | |
