C&K Components TFCJJ6VP004AC
- Mfg. Part Number
- TFCJJ6VP004AC
- Manufacturer
- C&K Components
- Product Category
- Snap Action, Limit Switches
- Brief Description
- SWITCH SNAP ACTION
- Datasheet Download
- TFCJJ6VP004AC.pdf
Availability of TFCJJ6VP004AC
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 4.74520
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of TFCJJ6VP004AC, we specialize in C&K Components all series electronic components. TFCJJ6VP004AC can be shipped within 24 hours after order. If you have any demands for TFCJJ6VP004AC, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- TFCJJ6VP004AC Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
TFCJJ6VP004AC
| Internal Part Number | EIS-TFCJJ6VP004AC | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Switches | |
| Family | Snap Action, Limit Switches | |
| Series | TF | |
| Packaging | Bulk | |
| Circuit | SPDT | |
| Switch Function | On-Mom | |
| Current Rating | 15A (AC), 500mA (DC) | |
| Voltage Rating - AC | 277V | |
| Voltage Rating - DC | 125V | |
| Actuator Type | Round (Pin Plunger) | |
| Mounting Type | Chassis Mount | |
| Termination Style | Quick Connect - 0.250" (6.3mm) | |
| Ingress Protection | - | |
| Features | - | |
| Operating Force, Torque | 150gf | |
| Release Force | 35gf | |
| Pretravel | 0.047" (1.2mm) | |
| Differential Travel | 0.010" (0.25mm) | |
| Overtravel | 0.050" (1.27mm) | |
| Operating Position | 0.579" (14.7mm) | |
| Mechanical Life | - | |
| Electrical Life | - | |
| Operating Temperature | -40°C ~ 85°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | TFCJJ6VP004AC | |
| Related Links | TFCJJ6, TFCJJ6VP004AC Datasheet, C&K Components Distributor | |
