Texas Instruments TIBPAL20R4-25CNT
- Mfg. Part Number
- TIBPAL20R4-25CNT
- Manufacturer
- Texas Instruments
- Product Category
- Embedded - PLDs (Programmable Logic Device)
- Brief Description
- IC PLD 25NS 24DIP
- Datasheet Download
- TIBPAL20R4-25CNT.pdf
Availability of TIBPAL20R4-25CNT
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of TIBPAL20R4-25CNT, we specialize in Texas Instruments all series electronic components. TIBPAL20R4-25CNT can be shipped within 24 hours after order. If you have any demands for TIBPAL20R4-25CNT, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- TIBPAL20R4-25CNT Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
TIBPAL20R4-25CNT
| Internal Part Number | EIS-TIBPAL20R4-25CNT | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| PCN Obsolescence/ EOL | Multiple Devices 08/Apr/2015 | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 15 | |
| Category | Integrated Circuits (ICs) | |
| Family | Embedded - PLDs (Programmable Logic Device) | |
| Series | IMPACT-X™ PAL® | |
| Packaging | Tube | |
| Programmable Type | PAL | |
| Number of Macrocells | - | |
| Voltage - Input | 5V | |
| Speed | 25ns | |
| Mounting Type | Through Hole | |
| Package / Case | 24-DIP (0.300", 7.62mm) | |
| Supplier Device Package | 24-PDIP | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | TIBPAL20R4-25CNT | |
| Related Links | TIBPAL20, TIBPAL20R4-25CNT Datasheet, Texas Instruments Distributor | |
TIBPAL20R4-25CNT Details Description
