Texas Instruments TL3016CDG4
- Mfg. Part Number
- TL3016CDG4
- Manufacturer
- Texas Instruments
- Product Category
- Linear - Comparators
- Brief Description
- IC PREC COMP ULTRA-FAST 8-SOIC
- Datasheet Download
- TL3016CDG4.pdf
Availability of TL3016CDG4
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.94250
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of TL3016CDG4, we specialize in Texas Instruments all series electronic components. TL3016CDG4 can be shipped within 24 hours after order. If you have any demands for TL3016CDG4, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- TL3016CDG4 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
TL3016CDG4
| Internal Part Number | EIS-TL3016CDG4 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 75 | |
| Category | Integrated Circuits (ICs) | |
| Family | Linear - Comparators | |
| Series | - | |
| Packaging | Tube | |
| Type | with Latch | |
| Number of Elements | 1 | |
| Output Type | Complementary, Push-Pull, TTL | |
| Voltage - Supply, Single/Dual (±) | 5 V ~ 10 V, ±2.5 V ~ 5 V | |
| Voltage - Input Offset (Max) | 3mV @ ±5V | |
| Current - Input Bias (Max) | 10µA @ ±5V | |
| Current - Output (Typ) | 20mA | |
| Current - Quiescent (Max) | 12.5mA | |
| CMRR, PSRR (Typ) | 97dB CMRR | |
| Propagation Delay (Max) | 10ns | |
| Hysteresis | - | |
| Operating Temperature | 0°C ~ 70°C | |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) | |
| Mounting Type | Surface Mount | |
| Supplier Device Package | 8-SOIC | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | TL3016CDG4 | |
| Related Links | TL301, TL3016CDG4 Datasheet, Texas Instruments Distributor | |
TL3016CDG4 Details Description
