Texas Instruments TLC374CPWG4
- Mfg. Part Number
- TLC374CPWG4
- Manufacturer
- Texas Instruments
- Product Category
- Linear - Comparators
- Brief Description
- IC DIFF COMPARATOR QUAD 14-TSSOP
- Datasheet Download
- TLC374CPWG4.pdf
Availability of TLC374CPWG4
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.87779
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of TLC374CPWG4, we specialize in Texas Instruments all series electronic components. TLC374CPWG4 can be shipped within 24 hours after order. If you have any demands for TLC374CPWG4, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- TLC374CPWG4 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
TLC374CPWG4
| Internal Part Number | EIS-TLC374CPWG4 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 90 | |
| Category | Integrated Circuits (ICs) | |
| Family | Linear - Comparators | |
| Series | LinCMOS™ | |
| Packaging | Tube | |
| Type | Differential | |
| Number of Elements | 4 | |
| Output Type | CMOS, MOS, Open-Drain, TTL | |
| Voltage - Supply, Single/Dual (±) | 3 V ~ 16 V, ±1.5 V ~ 8 V | |
| Voltage - Input Offset (Max) | 5mV @ 5V | |
| Current - Input Bias (Max) | 5pA @ 5V | |
| Current - Output (Typ) | 20mA | |
| Current - Quiescent (Max) | 800µA | |
| CMRR, PSRR (Typ) | - | |
| Propagation Delay (Max) | - | |
| Hysteresis | - | |
| Operating Temperature | 0°C ~ 70°C | |
| Package / Case | 14-TSSOP (0.173", 4.40mm Width) | |
| Mounting Type | Surface Mount | |
| Supplier Device Package | 14-TSSOP | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | TLC374CPWG4 | |
| Related Links | TLC37, TLC374CPWG4 Datasheet, Texas Instruments Distributor | |
