Texas Instruments TLC7524EN
- Mfg. Part Number
- TLC7524EN
- Manufacturer
- Texas Instruments
- Product Category
- Data Acquisition - Digital to Analog Converters (DAC)
- Brief Description
- IC DAC 8 BIT MULTIPLYING 16-DIP
- Datasheet Download
- TLC7524EN.pdf
Availability of TLC7524EN
Available Quantity
5170 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 2.10875
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of TLC7524EN, we specialize in Texas Instruments all series electronic components. TLC7524EN can be shipped within 24 hours after order. If you have any demands for TLC7524EN, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- TLC7524EN Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
TLC7524EN
| Internal Part Number | EIS-TLC7524EN | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Data Converter Basics | |
| PCN Design/Specification | Copper Bond Wire Revision A 04/Dec/2013 | |
| Manufacturer Product Page | TLC7524EN Specifications | |
| Standard Package | 25 | |
| Category | Integrated Circuits (ICs) | |
| Family | Data Acquisition - Digital to Analog Converters (DAC) | |
| Series | - | |
| Packaging | Tube | |
| Settling Time | 100ns | |
| Number of Bits | 8 | |
| Data Interface | Parallel | |
| Number of Converters | 1 | |
| Voltage Supply Source | Single Supply | |
| Operating Temperature | -40°C ~ 85°C | |
| Mounting Type | Through Hole | |
| Package / Case | 16-DIP (0.300", 7.62mm) | |
| Supplier Device Package | 16-PDIP | |
| Number of Outputs and Type | 2 Current, Unipolar; 2 Current, Bipolar | |
| Sampling Rate (Per Second) | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | TLC7524EN | |
| Related Links | TLC7, TLC7524EN Datasheet, Texas Instruments Distributor | |
TLC7524EN Details Description
