Infineon Technologies TLE4476D
.jpg)
- Mfg. Part Number
- TLE4476D
- Manufacturer
- Infineon Technologies
- Product Category
- PMIC - Voltage Regulators - Linear
- Brief Description
- IC REG LDO 3.3V/5V TO252-5
- Datasheet Download
- TLE4476D.pdf
Availability of TLE4476D
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of TLE4476D, we specialize in Infineon Technologies all series electronic components. TLE4476D can be shipped within 24 hours after order. If you have any demands for TLE4476D, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- TLE4476D Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
TLE4476D
| Internal Part Number | EIS-TLE4476D | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| PCN Obsolescence/ EOL | TLE4476D Devices 25/Nov/2013 | |
| PCN Packaging | Cover Tape Width Update 17/Jun/2015 Cover Tape Width Cancellation 14/Jul/2015 | |
| PCN Other | 8" Wafer Conversion Cancelled 02/Jul/2015 | |
| Standard Package | 2,500 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Voltage Regulators - Linear | |
| Series | Automotive, AEC-Q100 | |
| Packaging | Tape & Reel (TR) | |
| Regulator Topology | Positive Fixed | |
| Voltage - Output | 3.3V, 5V | |
| Current - Output | 350mA, 430mA | |
| Voltage - Dropout (Typical) | -, 0.3V @ 330mA | |
| Number of Regulators | 2 | |
| Voltage - Input | Up to 42V | |
| Current - Limit (Min) | 350mA, 430mA | |
| Operating Temperature | -40°C ~ 170°C | |
| Mounting Type | Surface Mount | |
| Package / Case | TO-252-5, DPak (4 Leads + Tab), TO-252AD | |
| Supplier Device Package | PG-TO252-5-11 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | TLE4476D | |
| Related Links | TLE4, TLE4476D Datasheet, Infineon Technologies Distributor | |
