Toshiba Semiconductor & Storage TLP351(TP1,F)
- Mfg. Part Number
- TLP351(TP1,F)
- Manufacturer
- Toshiba Semiconductor & Storage
- Product Category
- Isolators - Gate Drivers
- Brief Description
- OPTOISO 3.75KV GATE DRIVER 8SMD
- Datasheet Download
- TLP351(TP1,F).pdf
Availability of TLP351(TP1,F)
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.75625
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of TLP351(TP1,F), we specialize in Toshiba Semiconductor & Storage all series electronic components. TLP351(TP1,F) can be shipped within 24 hours after order. If you have any demands for TLP351(TP1,F), Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- TLP351(TP1,F) Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
TLP351(TP1,F)
| Internal Part Number | EIS-TLP351(TP1,F) | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | IC Photocoupler Overview | |
| Standard Package | 1,500 | |
| Category | Isolators | |
| Family | Isolators - Gate Drivers | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Technology | Optical Coupling | |
| Number of Channels | 1 | |
| Voltage - Isolation | 3750Vrms | |
| Common Mode Transient Immunity (Min) | 10kV/µs | |
| Propagation Delay tpLH / tpHL (Max) | 700ns, 700ns | |
| Pulse Width Distortion (Max) | - | |
| Rise / Fall Time (Typ) | 50ns, 50ns | |
| Current - Output High, Low | 400mA, 400mA | |
| Current - Peak Output | 600mA | |
| Voltage - Forward (Vf) (Typ) | 1.55V | |
| Current - DC Forward (If) (Max) | 20mA | |
| Voltage - Supply | 10 V ~ 30 V | |
| Operating Temperature | -40°C ~ 100°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 8-SMD, Gull Wing | |
| Supplier Device Package | 8-SMD | |
| Approvals | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | TLP351(TP1,F) | |
| Related Links | TLP351, TLP351(TP1,F) Datasheet, Toshiba Semiconductor & Storage Distributor | |
TLP351(TP1,F) Details Description
