Texas Instruments TMS320F28027DAT
- Mfg. Part Number
- TMS320F28027DAT
- Manufacturer
- Texas Instruments
- Product Category
- Embedded - Microcontrollers
- Brief Description
- IC MCU 32BIT 64KB FLASH 38TSSOP
- Datasheet Download
- TMS320F28027DAT.pdf
Availability of TMS320F28027DAT
Available Quantity
5172 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 3.43125
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of TMS320F28027DAT, we specialize in Texas Instruments all series electronic components. TMS320F28027DAT can be shipped within 24 hours after order. If you have any demands for TMS320F28027DAT, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- TMS320F28027DAT Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
TMS320F28027DAT
| Internal Part Number | EIS-TMS320F28027DAT | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 2 (1 Year) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | C2000 Motor Control PFC Kits Microcontrollers: ControlSUITE - Comprehensive software for the entire design process Motor Signal Chain Overview TPS75005 Single IC Power for C2000 MCU Evolution of the C2000 Microcontroller Platform Motor Control Solution InstaSPIN-BLDC Intro to Timers and Clocks Microcontrollers: SYS/BIOS: Introduction to Real-Time Operating Systems and SYS/BIOS | |
| Design Resources | Development Tool Selector | |
| PCN Assembly/Origin | AIZU Fabrication Facility 05/Sep/2013 | |
| Manufacturer Product Page | TMS320F28027DAT Specifications | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 40 | |
| Category | Integrated Circuits (ICs) | |
| Family | Embedded - Microcontrollers | |
| Series | C2000™ C28x Piccolo™ | |
| Packaging | Tube | |
| Core Processor | C28x | |
| Core Size | 32-Bit | |
| Speed | 60MHz | |
| Connectivity | I²C, SCI, SPI, UART/USART | |
| Peripherals | Brown-out Detect/Reset, POR, PWM, WDT | |
| Number of I/O | 20 | |
| Program Memory Size | 64KB (32K x 16) | |
| Program Memory Type | FLASH | |
| EEPROM Size | - | |
| RAM Size | 6K x 16 | |
| Voltage - Supply (Vcc/Vdd) | 1.71 V ~ 1.995 V | |
| Data Converters | A/D 7x12b | |
| Oscillator Type | Internal | |
| Operating Temperature | -40°C ~ 105°C | |
| Package / Case | 38-TSSOP (0.240", 6.10mm Width) | |
| Supplier Device Package | 38-TSSOP | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | TMS320F28027DAT | |
| Related Links | TMS320F, TMS320F28027DAT Datasheet, Texas Instruments Distributor | |
TMS320F28027DAT Details Description
