Vishay/Dale TNPW12062K05BETA
-TNP-SERIES.jpg)
- Mfg. Part Number
- TNPW12062K05BETA
- Manufacturer
- Vishay/Dale
- Product Category
- Chip Resistor - Surface Mount
- Brief Description
- RES SMD 2.05K OHM 0.1% 1/4W 1206
- Datasheet Download
- TNPW12062K05BETA.pdf
Availability of TNPW12062K05BETA
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.29624
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of TNPW12062K05BETA, we specialize in Vishay/Dale all series electronic components. TNPW12062K05BETA can be shipped within 24 hours after order. If you have any demands for TNPW12062K05BETA, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- TNPW12062K05BETA Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
TNPW12062K05BETA
| Internal Part Number | EIS-TNPW12062K05BETA | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 5,000 | |
| Category | Resistors | |
| Family | Chip Resistor - Surface Mount | |
| Series | TNPW | |
| Packaging | Tape & Reel (TR) | |
| Resistance (Ohms) | 2.05k | |
| Tolerance | ±0.1% | |
| Power (Watts) | 0.25W, 1/4W | |
| Composition | Thin Film | |
| Features | - | |
| Temperature Coefficient | ±25ppm/°C | |
| Operating Temperature | -55°C ~ 125°C | |
| Package / Case | 1206 (3216 Metric) | |
| Supplier Device Package | 1206 | |
| Size / Dimension | 0.126" L x 0.063" W (3.20mm x 1.60mm) | |
| Height | 0.026" (0.65mm) | |
| Number of Terminations | 2 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | TNPW12062K05BETA | |
| Related Links | TNPW1206, TNPW12062K05BETA Datasheet, Vishay/Dale Distributor | |
TNPW12062K05BETA Details Description
