Texas Instruments TPS2391DGKG4
- Mfg. Part Number
- TPS2391DGKG4
- Manufacturer
- Texas Instruments
- Product Category
- PMIC - Hot Swap Controllers
- Brief Description
- IC HOT SWAP PWR MGR 8VSSOP
- Datasheet Download
- TPS2391DGKG4.pdf
Availability of TPS2391DGKG4
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.35000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of TPS2391DGKG4, we specialize in Texas Instruments all series electronic components. TPS2391DGKG4 can be shipped within 24 hours after order. If you have any demands for TPS2391DGKG4, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- TPS2391DGKG4 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
TPS2391DGKG4
| Internal Part Number | EIS-TPS2391DGKG4 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 2 (1 Year) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 80 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Hot Swap Controllers | |
| Series | - | |
| Packaging | Tube | |
| Type | Hot Swap Controller | |
| Number of Channels | 1 | |
| Internal Switch(s) | No | |
| Applications | -48V | |
| Features | Auto Retry, UVLO | |
| Programmable Features | Current Limit, Fault Timeout, Slew Rate | |
| Voltage - Supply | -80 V ~ -36 V | |
| Current - Output (Max) | - | |
| Operating Temperature | -40°C ~ 85°C | |
| Current - Supply | 700µA | |
| Mounting Type | Surface Mount | |
| Package / Case | 8-TSSOP, 8-MSOP (0.118", 3.00mm Width) | |
| Supplier Device Package | 8-VSSOP | |
| Feature Pins | EN, /FAULT, FLTTIME, IRAMP | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | TPS2391DGKG4 | |
| Related Links | TPS239, TPS2391DGKG4 Datasheet, Texas Instruments Distributor | |
TPS2391DGKG4 Details Description
