Samtec, Inc. TSW-120-26-G-S
- Mfg. Part Number
- TSW-120-26-G-S
- Manufacturer
- Samtec, Inc.
- Product Category
- Rectangular Connectors - Headers, Male Pins
- Brief Description
- CONN HEADER 20POS .100" SGL GOLD
- Datasheet Download
- TSW-120-26-G-S.pdf
Availability of TSW-120-26-G-S
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.37464
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of TSW-120-26-G-S, we specialize in Samtec, Inc. all series electronic components. TSW-120-26-G-S can be shipped within 24 hours after order. If you have any demands for TSW-120-26-G-S, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- TSW-120-26-G-S Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
TSW-120-26-G-S
| Internal Part Number | EIS-TSW-120-26-G-S | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Board-to-Board Connectors | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 1 | |
| Category | Connectors, Interconnects | |
| Family | Rectangular Connectors - Headers, Male Pins | |
| Series | TSW | |
| Packaging | Bulk | |
| Contact Type | Male Pin | |
| Connector Type | Header, Unshrouded | |
| Number of Positions | 20 | |
| Number of Positions Loaded | All | |
| Pitch | 0.100" (2.54mm) | |
| Number of Rows | 1 | |
| Row Spacing | - | |
| Contact Mating Length | 0.230" (5.84mm) | |
| Mounting Type | Through Hole | |
| Termination | Solder | |
| Fastening Type | - | |
| Features | - | |
| Contact Finish | Gold | |
| Contact Finish Thickness | 10µin (0.25µm) | |
| Color | Black | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | TSW-120-26-G-S | |
| Related Links | TSW-120, TSW-120-26-G-S Datasheet, Samtec, Inc. Distributor | |
