Omron V-15-3C6-K
- Mfg. Part Number
- V-15-3C6-K
- Manufacturer
- Omron
- Product Category
- Snap Action, Limit Switches
- Brief Description
- SW SNAP 15A SPST-NO .250QC 250V
- Datasheet Download
- V-15-3C6-K.pdf
Availability of V-15-3C6-K
Available Quantity
5296 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.41862
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of V-15-3C6-K, we specialize in Omron all series electronic components. V-15-3C6-K can be shipped within 24 hours after order. If you have any demands for V-15-3C6-K, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- V-15-3C6-K Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
V-15-3C6-K
| Internal Part Number | EIS-V-15-3C6-K | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Other Related Documents | How to Read Date Codes | |
| Product Training Modules | Snap Switches | |
| Standard Package | 100 | |
| Category | Switches | |
| Family | Snap Action, Limit Switches | |
| Series | V | |
| Packaging | Bulk | |
| Circuit | SPST-NO | |
| Switch Function | Off-Mom | |
| Current Rating | 15A (AC), 10A (DC) | |
| Voltage Rating - AC | 250V | |
| Voltage Rating - DC | 30V | |
| Actuator Type | Round (Pin Plunger) | |
| Mounting Type | Chassis Mount | |
| Termination Style | Quick Connect - 0.250" (6.3mm) | |
| Ingress Protection | IP40 | |
| Features | - | |
| Operating Force, Torque | 400gf | |
| Release Force | 80gf | |
| Pretravel | 0.047" (1.2mm) | |
| Differential Travel | 0.016" (0.4mm) | |
| Overtravel | 0.040" (1.0mm) | |
| Operating Position | 0.579" (14.7mm) | |
| Mechanical Life | 50,000,000 Cycles | |
| Electrical Life | 100,000 Cycles | |
| Operating Temperature | -25°C ~ 80°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | V-15-3C6-K | |
| Related Links | V-15-, V-15-3C6-K Datasheet, Omron Distributor | |
V-15-3C6-K Details Description
