CUI Inc. VIBLSD1-S24-S15-DIP
- Mfg. Part Number
- VIBLSD1-S24-S15-DIP
- Manufacturer
- CUI Inc.
- Product Category
- DC DC Converters
- Brief Description
- CONVERTER DC/DC 15V REG OUT 1W
- Datasheet Download
- VIBLSD1-S24-S15-DIP.pdf
Availability of VIBLSD1-S24-S15-DIP
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 5.11500
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of VIBLSD1-S24-S15-DIP, we specialize in CUI Inc. all series electronic components. VIBLSD1-S24-S15-DIP can be shipped within 24 hours after order. If you have any demands for VIBLSD1-S24-S15-DIP, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- VIBLSD1-S24-S15-DIP Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
VIBLSD1-S24-S15-DIP
| Internal Part Number | EIS-VIBLSD1-S24-S15-DIP | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Thermal Management of Power Supplies | |
| RoHS Information | VIBLSD1-DIP Series Cert of Compliance | |
| 3D Model | VIBLSD1-S24-S15-DIP | |
| Other Drawings | VIBLSD1 Series Dip Bottom VIBLSD1 Series Dip Side | |
| Standard Package | 25 | |
| Category | Power Supplies - Board Mount | |
| Family | DC DC Converters | |
| Series | VIBLSD1-DIP | |
| Packaging | - | |
| Type | Isolated Module | |
| Number of Outputs | 1 | |
| Voltage - Input (Min) | 22.8V | |
| Voltage - Input (Max) | 25.2V | |
| Voltage - Output 1 | 15V | |
| Voltage - Output 2 | - | |
| Voltage - Output 3 | - | |
| Current - Output (Max) | 67mA | |
| Power (Watts) - Manufacture Series | 1W | |
| Voltage - Isolation | 1kV (1000V) | |
| Features | SCP | |
| Mounting Type | Through Hole | |
| Package / Case | 14-DIP Module (300 mil, 5 Leads) | |
| Size / Dimension | 0.80" L x 0.39" W x 0.26" H (20.4mm x 10.0mm x 6.5mm) | |
| Operating Temperature | -40°C ~ 85°C | |
| Efficiency | 73% | |
| Power (Watts) - Max | 1W | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | VIBLSD1-S24-S15-DIP | |
| Related Links | VIBLSD1-S, VIBLSD1-S24-S15-DIP Datasheet, CUI Inc. Distributor | |
VIBLSD1-S24-S15-DIP Details Description
